What is Distributed Tracing? Concepts & OpenTelemetry Implementation

_, span := tracer.Start(ctx, "handle_request",
    trace.WithSpanKind(trace.SpanKindServer),
    trace.WithAttributes(
        semconv.HTTPMethod("GET"),
        semconv.HTTPRoute("/api/users/:id"),
    ))
defer span.End()

with tracer.start_as_current_span(
    "handle_request",
    kind=trace.SpanKind.SERVER,
    attributes={
        "http.method": "GET",
        "http.route": "/api/users/:id",
    }
) as span:
    # Handle request
    pass

const span = tracer.startSpan('handle_request', {
  kind: trace.SpanKind.SERVER,
  attributes: {
    'http.method': 'GET',
    'http.route': '/api/users/:id',
  }
});
// Handle request
span.end();

_, span := tracer.Start(ctx, "database_query",
    trace.WithSpanKind(trace.SpanKindClient),
    trace.WithAttributes(
        semconv.DBSystemPostgreSQL,
        semconv.DBQueryText("SELECT * FROM users WHERE id = ?"),
    ))
defer span.End()

with tracer.start_as_current_span(
    "database_query",
    kind=trace.SpanKind.CLIENT,
    attributes={
        "db.system": "postgresql",
        "db.query.text": "SELECT * FROM users WHERE id = ?",
    }
) as span:
    # Execute query
    pass

const span = tracer.startSpan('database_query', {
  kind: trace.SpanKind.CLIENT,
  attributes: {
    'db.system': 'postgresql',
    'db.query.text': 'SELECT * FROM users WHERE id = ?',
  }
});
// Execute query
span.end();

_, span := tracer.Start(ctx, "publish_event",
    trace.WithSpanKind(trace.SpanKindProducer),
    trace.WithAttributes(
        semconv.MessagingSystemKafka,
        semconv.MessagingDestinationName("user.events"),
    ))
defer span.End()

with tracer.start_as_current_span(
    "publish_event",
    kind=trace.SpanKind.PRODUCER,
    attributes={
        "messaging.system": "kafka",
        "messaging.destination.name": "user.events",
    }
) as span:
    # Publish message
    pass

const span = tracer.startSpan('publish_event', {
  kind: trace.SpanKind.PRODUCER,
  attributes: {
    'messaging.system': 'kafka',
    'messaging.destination.name': 'user.events',
  }
});
// Publish message
span.end();

_, span := tracer.Start(ctx, "process_message",
    trace.WithSpanKind(trace.SpanKindConsumer),
    trace.WithAttributes(
        semconv.MessagingSystemKafka,
        semconv.MessagingOperationProcess,
    ))
defer span.End()

with tracer.start_as_current_span(
    "process_message",
    kind=trace.SpanKind.CONSUMER,
    attributes={
        "messaging.system": "kafka",
        "messaging.operation.type": "process",
    }
) as span:
    # Process message
    pass

const span = tracer.startSpan('process_message', {
  kind: trace.SpanKind.CONSUMER,
  attributes: {
    'messaging.system': 'kafka',
    'messaging.operation.type': 'process',
  }
});
// Process message
span.end();

_, span := tracer.Start(ctx, "calculate_total",
    trace.WithSpanKind(trace.SpanKindInternal),
    trace.WithAttributes(
        attribute.Int("item_count", len(items)),
    ))
defer span.End()

with tracer.start_as_current_span(
    "calculate_total",
    kind=trace.SpanKind.INTERNAL,
    attributes={
        "item_count": len(items),
    }
) as span:
    # Calculate total
    pass

const span = tracer.startSpan('calculate_total', {
  kind: trace.SpanKind.INTERNAL,
  attributes: {
    'item_count': items.length,
  }
});
// Calculate total
span.end();

import (
    "go.opentelemetry.io/otel"
    "go.opentelemetry.io/otel/propagation"
)

// Create a new span
ctx, span := tracer.Start(ctx, "external_api_call")
defer span.End()

// Create HTTP request
req, _ := http.NewRequestWithContext(ctx, "GET", "https://api.example.com/data", nil)

// Inject trace context into request headers
otel.GetTextMapPropagator().Inject(ctx, propagation.HeaderCarrier(req.Header))

// Make the request
resp, err := http.DefaultClient.Do(req)

from opentelemetry import trace
from opentelemetry.propagate import inject
import requests

# Create a new span
with tracer.start_as_current_span("external_api_call"):
    headers = {}

    # Inject trace context into headers
    inject(headers)

    # Make the request
    response = requests.get("https://api.example.com/data", headers=headers)

const { trace, context, propagation } = require('@opentelemetry/api');
const axios = require('axios');

// Create a new span
const span = tracer.startSpan('external_api_call');

context.with(trace.setSpan(context.active(), span), () => {
  const headers = {};

  // Inject trace context into headers
  propagation.inject(context.active(), headers);

  // Make the request
  axios.get('https://api.example.com/data', { headers })
    .finally(() => span.end());
});

import (
    "go.opentelemetry.io/otel"
    "go.opentelemetry.io/otel/propagation"
)

func handler(w http.ResponseWriter, r *http.Request) {
    // Extract trace context from incoming request headers
    ctx := otel.GetTextMapPropagator().Extract(r.Context(),
        propagation.HeaderCarrier(r.Header))

    // Create span with extracted context
    ctx, span := tracer.Start(ctx, "handle_request")
    defer span.End()

    // Process request with traced context
    processRequest(ctx, r)
}

from opentelemetry import trace
from opentelemetry.propagate import extract
from flask import Flask, request

app = Flask(__name__)

@app.route('/api/endpoint')
def handle_request():
    # Extract trace context from incoming headers
    ctx = extract(request.headers)

    # Create span with extracted context
    with tracer.start_as_current_span("handle_request", context=ctx):
        # Process request with traced context
        return process_request()

const { trace, context, propagation } = require('@opentelemetry/api');
const express = require('express');

const app = express();

app.get('/api/endpoint', (req, res) => {
  // Extract trace context from incoming headers
  const extractedContext = propagation.extract(context.active(), req.headers);

  // Create span with extracted context
  const span = tracer.startSpan('handle_request', {}, extractedContext);

  context.with(trace.setSpan(extractedContext, span), () => {
    // Process request with traced context
    processRequest(req, res);
    span.end();
  });
});

import (
    "context"
    "go.opentelemetry.io/otel"
    "go.opentelemetry.io/otel/attribute"
    "go.opentelemetry.io/otel/codes"
    "go.opentelemetry.io/otel/trace"
)

// Get tracer (typically done once at startup)
tracer := otel.Tracer("my-service")

func processOrder(ctx context.Context, orderID string) error {
    // Create a span
    ctx, span := tracer.Start(ctx, "process_order",
        trace.WithSpanKind(trace.SpanKindInternal),
    )
    defer span.End()

    // Add attributes
    span.SetAttributes(
        attribute.String("order.id", orderID),
        attribute.String("customer.tier", "premium"),
    )

    // Do work
    if err := validateOrder(ctx, orderID); err != nil {
        // Record error
        span.RecordError(err)
        span.SetStatus(codes.Error, "order validation failed")
        return err
    }

    // Record event
    span.AddEvent("order_validated",
        trace.WithAttributes(
            attribute.String("validation.result", "success"),
        ))

    span.SetStatus(codes.Ok, "order processed successfully")
    return nil
}

from opentelemetry import trace
from opentelemetry.trace import Status, StatusCode

tracer = trace.get_tracer("my-service")

def process_order(order_id: str):
    with tracer.start_as_current_span(
        "process_order",
        kind=trace.SpanKind.INTERNAL,
    ) as span:
        # Add attributes
        span.set_attributes({
            "order.id": order_id,
            "customer.tier": "premium",
        })

        try:
            validate_order(order_id)

            # Record event
            span.add_event("order_validated", {
                "validation.result": "success"
            })

            span.set_status(Status(StatusCode.OK))

        except Exception as e:
            # Record error
            span.record_exception(e)
            span.set_status(Status(StatusCode.ERROR, "order validation failed"))
            raise

const { trace } = require('@opentelemetry/api');
const { SpanStatusCode } = require('@opentelemetry/api');

const tracer = trace.getTracer('my-service');

function processOrder(orderId) {
  const span = tracer.startSpan('process_order', {
    kind: trace.SpanKind.INTERNAL,
  });

  // Add attributes
  span.setAttributes({
    'order.id': orderId,
    'customer.tier': 'premium',
  });

  try {
    validateOrder(orderId);

    // Record event
    span.addEvent('order_validated', {
      'validation.result': 'success'
    });

    span.setStatus({ code: SpanStatusCode.OK });

  } catch (error) {
    // Record error
    span.recordException(error);
    span.setStatus({
      code: SpanStatusCode.ERROR,
      message: 'order validation failed'
    });
    throw error;

  } finally {
    span.end();
  }
}

func processOrder(ctx context.Context, orderID string) error {
    ctx, span := tracer.Start(ctx, "process_order")
    defer span.End()

    // Child span 1: Validate
    if err := validateOrder(ctx, orderID); err != nil {
        return err
    }

    // Child span 2: Calculate
    total, err := calculateTotal(ctx, orderID)
    if err != nil {
        return err
    }

    // Child span 3: Save
    return saveOrder(ctx, orderID, total)
}

func validateOrder(ctx context.Context, orderID string) error {
    ctx, span := tracer.Start(ctx, "validate_order")
    defer span.End()

    // Validation logic
    return nil
}

func calculateTotal(ctx context.Context, orderID string) (float64, error) {
    ctx, span := tracer.Start(ctx, "calculate_total")
    defer span.End()

    // Calculation logic
    return 99.99, nil
}

func saveOrder(ctx context.Context, orderID string, total float64) error {
    ctx, span := tracer.Start(ctx, "save_order",
        trace.WithSpanKind(trace.SpanKindClient),
    )
    defer span.End()

    span.SetAttributes(
        attribute.Float64("order.total", total),
        attribute.String("db.system", "postgresql"),
    )

    // Database save logic
    return nil
}

def process_order(order_id: str):
    with tracer.start_as_current_span("process_order") as span:
        # Child span 1: Validate
        validate_order(order_id)

        # Child span 2: Calculate
        total = calculate_total(order_id)

        # Child span 3: Save
        save_order(order_id, total)

def validate_order(order_id: str):
    with tracer.start_as_current_span("validate_order"):
        # Validation logic
        pass

def calculate_total(order_id: str) -> float:
    with tracer.start_as_current_span("calculate_total"):
        # Calculation logic
        return 99.99

def save_order(order_id: str, total: float):
    with tracer.start_as_current_span(
        "save_order",
        kind=trace.SpanKind.CLIENT,
        attributes={
            "order.total": total,
            "db.system": "postgresql",
        }
    ):
        # Database save logic
        pass

function processOrder(orderId) {
  const span = tracer.startSpan('process_order');

  try {
    // Child span 1: Validate
    validateOrder(orderId);

    // Child span 2: Calculate
    const total = calculateTotal(orderId);

    // Child span 3: Save
    saveOrder(orderId, total);
  } finally {
    span.end();
  }
}

function validateOrder(orderId) {
  const span = tracer.startSpan('validate_order');
  try {
    // Validation logic
  } finally {
    span.end();
  }
}

function calculateTotal(orderId) {
  const span = tracer.startSpan('calculate_total');
  try {
    // Calculation logic
    return 99.99;
  } finally {
    span.end();
  }
}

function saveOrder(orderId, total) {
  const span = tracer.startSpan('save_order', {
    kind: trace.SpanKind.CLIENT,
    attributes: {
      'order.total': total,
      'db.system': 'postgresql',
    }
  });
  try {
    // Database save logic
  } finally {
    span.end();
  }
}

import "go.opentelemetry.io/otel/semconv/v1.24.0"

// HTTP attributes
span.SetAttributes(
    semconv.HTTPMethod("GET"),
    semconv.HTTPRoute("/api/users/:id"),
    semconv.HTTPStatusCode(200),
)

// Database attributes
span.SetAttributes(
    semconv.DBSystemPostgreSQL,
    semconv.DBNamespace("production"),
    semconv.DBQueryText("SELECT * FROM users WHERE id = ?"),
)

// Messaging attributes
span.SetAttributes(
    semconv.MessagingSystemKafka,
    semconv.MessagingDestinationName("user.events"),
)

// RPC attributes
span.SetAttributes(
    semconv.RPCSystemGRPC,
    semconv.RPCService("UserService"),
    semconv.RPCMethod("GetUser"),
)

from opentelemetry.semconv.trace import SpanAttributes

# HTTP attributes
span.set_attributes({
    SpanAttributes.HTTP_METHOD: "GET",
    SpanAttributes.HTTP_ROUTE: "/api/users/:id",
    SpanAttributes.HTTP_STATUS_CODE: 200,
})

# Database attributes
span.set_attributes({
    SpanAttributes.DB_SYSTEM: "postgresql",
    SpanAttributes.DB_NAMESPACE: "production",
    SpanAttributes.DB_QUERY_TEXT: "SELECT * FROM users WHERE id = ?",
})

# Messaging attributes
span.set_attributes({
    SpanAttributes.MESSAGING_SYSTEM: "kafka",
    SpanAttributes.MESSAGING_DESTINATION_NAME: "user.events",
})

# RPC attributes
span.set_attributes({
    SpanAttributes.RPC_SYSTEM: "grpc",
    SpanAttributes.RPC_SERVICE: "UserService",
    SpanAttributes.RPC_METHOD: "GetUser",
})

const { SEMATTRS_HTTP_METHOD, SEMATTRS_HTTP_ROUTE, SEMATTRS_HTTP_STATUS_CODE,
        SEMATTRS_DB_SYSTEM, SEMATTRS_DB_NAMESPACE, SEMATTRS_DB_QUERY_TEXT,
        SEMATTRS_MESSAGING_SYSTEM, SEMATTRS_MESSAGING_DESTINATION_NAME,
        SEMATTRS_RPC_SYSTEM, SEMATTRS_RPC_SERVICE, SEMATTRS_RPC_METHOD
} = require('@opentelemetry/semantic-conventions');

// HTTP attributes
span.setAttributes({
  [SEMATTRS_HTTP_METHOD]: 'GET',
  [SEMATTRS_HTTP_ROUTE]: '/api/users/:id',
  [SEMATTRS_HTTP_STATUS_CODE]: 200,
});

// Database attributes
span.setAttributes({
  [SEMATTRS_DB_SYSTEM]: 'postgresql',
  [SEMATTRS_DB_NAMESPACE]: 'production',
  [SEMATTRS_DB_QUERY_TEXT]: 'SELECT * FROM users WHERE id = ?',
});

// Messaging attributes
span.setAttributes({
  [SEMATTRS_MESSAGING_SYSTEM]: 'kafka',
  [SEMATTRS_MESSAGING_DESTINATION_NAME]: 'user.events',
});

// RPC attributes
span.setAttributes({
  [SEMATTRS_RPC_SYSTEM]: 'grpc',
  [SEMATTRS_RPC_SERVICE]: 'UserService',
  [SEMATTRS_RPC_METHOD]: 'GetUser',
});

// Record a simple event
span.AddEvent("cache_miss")

// Event with attributes
span.AddEvent("retry_attempt",
    trace.WithAttributes(
        attribute.Int("attempt.number", 3),
        attribute.String("retry.reason", "connection_timeout"),
    ))

// Record an error
if err != nil {
    span.RecordError(err,
        trace.WithAttributes(
            attribute.String("error.type", "ValidationError"),
        ))
    span.SetStatus(codes.Error, err.Error())
}

# Record a simple event
span.add_event("cache_miss")

# Event with attributes
span.add_event("retry_attempt", {
    "attempt.number": 3,
    "retry.reason": "connection_timeout"
})

# Record exception with stack trace
try:
    risky_operation()
except Exception as e:
    span.record_exception(e)  # Automatically captures stack trace
    span.set_status(Status(StatusCode.ERROR))
    raise

// Record a simple event
span.addEvent('cache_miss');

// Event with attributes
span.addEvent('retry_attempt', {
  'attempt.number': 3,
  'retry.reason': 'connection_timeout'
});

// Record an error
if (error) {
  span.recordException(error);
  span.setStatus({
    code: SpanStatusCode.ERROR,
    message: error.message
  });
}
